Description
Features
- LC178F engine, the secondary generation of single cylinder diesel engine of Loncin, is used, which provides lower unit fuel consumption, more powerful output and economical fuel consumption.
-
The machine is featured with compact structure, light weight, easy operation and perfectly suitable for agricultural operation in mountainous and hilly regions.
-
High adaptability and multiple functions. Provided with different farming tools, the machine can be used for either dry land operation or paddy field rotary tillage. It can also be used for pumping, irrigation, spraying, threshing when equipped with special machines and tools.
-
The range of tillage width is up to 135cm.
-
The tillage depth is controlled by easy-adjusted damping arm.
-
Its height can be adjusted for three levels and adjusted leftwards and rightwards, which is easy to operate.
-
Wheel replacement is easy.
-
With features such as easy maintenance, reliable performance and multifunction corresponding to agriculture needs of different areas, the machine is the perfect mini agricultural machinery to replace traditional cattle farming of mountainous areas.
Technical Details
| Model | 1WG4.9-135FC-Z | |
| Engine | Engine Model | LC178F/D350F |
| Rated power | 4.9kW | |
| Rated speed | 3600 r/min | |
| Displacement | 349CC | |
| Gas oil capacity | 3.5L | |
| Oil capacity | 1.1L | |
| Fuel consumption | ≤25 kg /hm2 | |
| Tiller | Cutting width | 135cm |
| Cutting depth | ≥18 cm | |
| working capacity | 0.1～0.3 m/s | |
| Efficiency per hour | ≥750m2/h | |
| Transmission | Gear | |
| Connecting | Straight | |
| Rated blade speed | 120r/min | |
| Blade Type | Dryland blade | |
| Dimension | 1500 ×1050 × 1000mm | |
| Net weight (Kg) | 131kg/145kg | |
